MINI MCR-SL-PT100-UI-NC -

Amplifier, Pt100, MINI MCR-SL-PT100-UI-NC, Phoenix Contact

Phoenix Contact MINI MCR-SL-PT100-UI-NC
声明:图片仅供参考,请以实物为准!
制造商产品编号:
MINI MCR-SL-PT100-UI-NC
仓库库存编号:
176-89-586
技术数据表:
View MINI MCR-SL-PT100-UI-NC Datasheet Datasheet
订购热线: 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大,部分产品信息可能未能及时更新,下单前请与销售人员确认好实时在库数量,谢谢合作!

MINI MCR-SL-PT100-UI-NC技术参数

Operating voltage 19.2...30 VDC
Temperature measurement range -150...+850 °C
Input, resistance thermometer Pt100
Output, analogue 0...10 V
0/1...5 V
0/4...20 mA
10...0 VDC
20...0/4 mA

MINI MCR-SL-PT100-UI-NC产品信息

Design Measuring transformer
Operating temperature -20...+65 °C
Manufacturer Article n° 2864273
Protection rating IP 20
Dimensions W x H x D 6.2 x 93 x 102.5 mm

MINI MCR-SL-PT100-UI-NC您可能还对以下元器件感兴趣

电话:400-900-3095
QQ:800152669

MINI MCR-SL-PT100-UI-NCFamily Information

  • Pt100 with 2, 3 or 4-wire connection
  • Measurement ranges of -150...850/1350 °C (Pt100/TC) configurable
  • 3-way isolation, configurable output signals, can also be inverted
  • Diagnostic LED for fault analysis
  • Screw connections
  • Mounting in any position
  • Power supply possible via foot component
  • Suitable power supply: MINI-SYS-PS-100-240AC/24DC/1.5
  • Bridging of supply voltage to further units possible via bus link

MINI MCR-SL-PT100-UI-NC产地与重量

Country of origin Germany (DE)
Manufacturer Phoenix Contact
Gross weight (incl. package) 54.0 Gram
Dimensions (incl. package) 105 x 95 x 10 MM
Customs number 8504318090
UNSPSC (v5.03) 41113637
EAN 4017918956561
