135-39-661,DIL switch THD 8P, 3-435640-9, TE Connectivity
Datasheet
| Pitch | 2.54 mm |
| Poles | 8 |
| Switching capacity | 25 mA@ 24 VDC |
| Connection | THD |
| Contact resistance | <100 mOhm |
| Insulation resistance | >100 MOhm |
| Dimensions L x W x H | 22.35 x 9.65 x 8.64 mm |
| Contact material | Au |
| Test voltage | 300 V |
| Actuation | above, raised |
| Height | 8.64 mm |
| Length | 22.35 mm |
| Width | 9.65 mm |
| Description | With Plastisol covering |
| Temperature range | -20...+85 °C |
