110-57-467,Energy Logger 1000 VAC 1500 AAC, FLUKE-1730/EU, Fluke
Datasheet
| Application | Three-phase |
| Inputs | 4 voltage and 3 current inputs |
| VAC max. | 1000 VAC |
| AAC max. | 1500 AAC |
| Bandwidth | 50 Hz/60 Hz |
| Safety to EN61010 |
CAT III 1000 V
CAT IV 600 V |
| Interfaces | USB |
| Measuring function |
A
COS ф Data logger Hz PF THD V VA VAr W Wh |
| Basic accuracy, voltage, AC/DC | ±0.2 % |
| Basic accuracy, current, AC/DC | ±1% |
| VAC resolution | 100 mV |
| AAC resolution | 100 mA |
| Display | 4.3" LCD Touch Screen |
| Electrical supply |
100...240 V @ 50...60 Hz
100...500 VAC Li-ion battery |
| Dimensions L x W x H | 198 x 167 x 55 mm |
| Weight | 1.1 kg |
| Protection rating | IP 50 |
| Delivery with |
Carrying case
Crocodile clip Current Clamp x 3 Documentation CD Memory card Power cable Power supply Test lead USB cable |
