TR 10 -

Linear Position Sensor 10 mm 1 kOhm, TR 10, Novotechnik

Novotechnik TR 10
声明:图片仅供参考,请以实物为准!
制造商产品编号:
TR 10
仓库库存编号:
164-90-428
技术数据表:
View TR 10 Datasheet Datasheet
订购热线: 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大,部分产品信息可能未能及时更新,下单前请与销售人员确认好实时在库数量,谢谢合作!

TR 10技术参数

Stroke length, electric 10 mm
Linearity ≤±0.2 %
Service life >100 x 106 movements
Output Voltage divider

TR 10产品信息

Length 48 mm
Dimensions L x W x H 48 x 18 x 19 mm
Return spring Yes
Connection Cable 2 m
Resistance 1 kOhm
Operating voltage max. 24 V
Repeat accuracy 0.002 mm
Tolerance, resistance ±20 %
Operating temperature -30...+100 °C
Protection rating IP 40
Temperature coefficient 5 ppm/°C
A 48 mm
B 15 mm
C 7 mm
D 21 mm
Housing Material Anodized
Aluminium (Al)
电话:400-900-3095
QQ:800152669

TR 10Family Information

Series Description
  • Conductive plastic potentiometer
  • Connector or cable output 2 m
  • Compact design
  • Return spring

TR 10产地与重量

Country of origin Germany (DE)
Manufacturer Novotechnik
Gross weight (incl. package) 126.0 Gram
Dimensions (incl. package) 210 x 100 x 25 MM
Customs number 8533401000
UNSPSC (v5.03) 32121603
