176-09-213,Multimeter digital FLUKE 289/EUR TRMS AC+DC 50000 digits 1000 VAC 1000 VDC 10 ADC, FLUKE 289/EUR, Fluke
Datasheet
| Type of measurement | TRMS AC+DC |
| Display | 50000 digits |
| Bandwidth VAC | 100 kHz |
| Bandwidth AAC | 100 kHz |
| Safety to EN61010 |
CAT III 1000 V
CAT IV 600 V |
| VAC max. | 1000 VAC |
| VAC resolution | 1 μV |
| VDC max. | 1000 VDC |
| VDC resolution | 1 μV |
| ADC max. | 10 ADC |
| ADC resolution | 0.01 μA |
| AAC max. | 10 AAC |
| AAC resolution | 0.01 μA |
| Ohm max. | 500 MOhm |
| Ohm resolution | 10 mOhm |
| F max. | 100 mF |
| F resolution | 0.001 nF |
| Hz max. | 1 MHz |
| Hz resolution | 0.01 Hz |
| Sensor type/thermocouples | K |
| °C measurement range | -200...+1350 °C |
| °C resolution | 0.1 °C |
| dBm / dBV max. | +60 dB |
| dBm / dBV resolution | 0.01 dB |
| Measuring function |
Continuity tester
Diode tester Hold Internal memory Data logger Min./max. value Relative mode |
| Instrument functions |
Analogue bargraph
Backlight Integrated holster |
| Interfaces | USB |
| Electrical supply | 6 x LR6/AA |
| Guarantee | Lifetime |
| Dimensions L x W x H | 222 x 102 x 60 mm |
| Weight | 871 g |
| Description | Digital multimeter |
| Design | Handheld |
| Delivery with |
Battery
Holster Manual Test lead |
