110-81-956,Multimeter digital TRMS AC+DC 6000 digits 1000 VAC 1000 VDC 10 ADC, APPA 99III, Appa
| Type of measurement | TRMS AC+DC |
| Display | 6000 digits |
| Safety to EN61010 |
CAT III 1000 V
CAT IV 600 V |
| VAC max. | 1000 VAC |
| VAC resolution | 1000 μV |
| VDC max. | 1000 VDC |
| VDC resolution | 100 μV |
| ADC max. | 10 ADC |
| ADC resolution | 10 μA |
| AAC max. | 10 AAC |
| AAC resolution | 10 μA |
| Ohm max. | 40 MOhm |
| Ohm resolution | 10 Ohm |
| Series | Appa 90III |
| F max. | 10 mF |
| F resolution | 1 nF |
| Hz max. | 100 kHz |
| Hz resolution | 0.01 Hz |
| °C measurement range | -40...400 °C |
| °C resolution | 0.1 °C |
| Measuring function |
Continuity tester
Diode tester Hold LowZ (low impedance) Input for Voltage measurements Min./max. value |
| Instrument functions |
Analogue bargraph
Backlight Frequency counter Non-contact voltage detection |
| Electrical supply | 1 x 6LR61/9V |
| Dimensions L x W x H | 94 x 190 x 48 mm |
| Weight | 460 g |
| Design | Handheld |
| Delivery with |
Battery
Magnetic hanging kit Manual Temperature probe Test lead Spare-Fuse |
