300-68-203,Oscilloscope 2x100 MHz 1 GS/s, TBS2102, Tektronix
Datasheet
| Series | TBS2000 |
| Channel analog | 2 |
| Channel digital (MSO) | 0 |
| Bandwidth | 100 MHz |
| Sample rate, single-shot | 1 GS/s |
| Display | 9" TFT-LCD |
| Trigger |
Auto
Normal Single Edge Pulse width Runt |
| Safety standard EN 61010 | CAT II 300 V |
| Interfaces | USB |
| Type of measurement | RMS |
| Measuring function |
Period
Frequency Delay Rise Time Fall Time Duty cycle Pulse Width Burst Width Phase Overshoot Peak-to-Peak Amplitude High/Low Min./max. value Mean Cycle Mean RMS Cycle RMS Pulse Count Edge Count Area Cycle Area Delay FR Delay FF Delay RR |
| Vertical sensitivity/div | 2 mV...5 V/div |
| Time basis | 2.5 ns/div...100 s/div |
| Vertical resolution | 8 Bit |
| Electrical supply | 100...240 V @ 45...65 Hz |
| Mathematical functions |
Add
Subtract Multiply FFT |
| Input coupling |
AC
DC GND |
| Input impedance Ohm | 1 MOhm |
| Input: Impedance F | 11.5 pF |
| Dimensions L x W x H | 103.3 x 372.4 x 174.9 mm |
| Weight | 2.62 g |
| Guarantee | 5 years |
| Delivery with |
1 Probes/channel
Documentation CD Manual Power cable Software Calibration certificate |
Designed to make your work easier and for outstanding waveform visualization and analysis. The TBS2000 series digital storage oscilloscope captures and displays significantly more signal to help you evaluate designs faster. Easily and confidently analyze your signals with new on-waveform cursor readouts and 32 automatic measurements, each with informative tips to help you choose the right one. The TekVPI probe interface works with traditional BNC connections, but also enables wide application coverage with active voltage probes and current probes.
