1801.1202 -

Rocker switch 1P 4 A 250 VAC, 1801.1202, Marquardt

Marquardt 1801.1202
声明：图片仅供参考，请以实物为准！
制造商产品编号：
1801.1202
仓库库存编号：
135-03-109
技术数据表：
View 1801.1202 Datasheet Datasheet
订购热线： 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大，部分产品信息可能未能及时更新，下单前请与销售人员确认好实时在库数量，谢谢合作！

1801.1202技术参数

Switching type, ( )momentary off-(on)
Termination type Blade Terminal 4.8 x 0.8 mm
Rated voltage 250 VAC
Poles 1
Series 1800
Rated current 4 A
Rocker black

1801.1202产品信息

Contact material Ag
Assembly cutout 19.2 x 12.9 mm at wall thickness of 0.7...1.25 mm, 19.4 x 12.9 mm at wall thickness of 1.25...2 mm, 19.8 x 12.9 mm at wall thickness of 2...3 mm
Protection rating IP 40
Housing black
Temperature range -20...+55 °C

1801.1202配套产品

  • 参考图片
  • 制造商 / 说明 / 型号 / 仓库库存编号
  • PDF
  • 操作
Related Categories: Switches | Pushbutton Switches | Switch Components & Accessories
Related Products: Micro switch 5 A Plunger N/A 1 change-over (CO) | Flat lever | Slide switch on-on 1P | Micro switch 5 A Plunger N/A 1 change-over (CO) | Toggle switch Standard Lever on-on 1P
Related Manufacturers: Apem | EAO | RAFI | Omron Electronic Components | NKK
电话:400-900-3095
QQ:800152669

1801.1202Family Information

  • Distinctive activation characteristic
  • Simple lock-in assembly
  • Fixed seating in device cut-out through tolerance compensation ribs on switch housing

1801.1202产地与重量

Country of origin Germany (DE)
Manufacturer Marquardt
Gross weight (incl. package) 4.0 Gram
Dimensions (incl. package) 28 x 10 x 10 MM
Customs number 8536508099
UNSPSC (v5.03) 30211908
