NPORT 5410 -

Serial Server 4x RS232, NPORT 5410, Moxa

Moxa NPORT 5410
声明:图片仅供参考,请以实物为准!
制造商:
Moxa Moxa
制造商产品编号:
NPORT 5410
仓库库存编号:
125-73-458
技术数据表:
View NPORT 5410 Datasheet Datasheet
订购热线: 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大,部分产品信息可能未能及时更新,下单前请与销售人员确认好实时在库数量,谢谢合作!

NPORT 5410技术参数

Serial connections DB9 Male

NPORT 5410产品信息

Interfaces 4x RS232
WLAN -
LAN ports 1x 10/100
Power supply 12...48 VDC
Related Categories: Networking | Industrial Communication | Entertainment & TVs | PC Components | Peripherals
Related Manufacturers: Visaton | Maxxtro | Exsys | Encitech Connectors | K?nig
Related Products: RJ45 plug Cat5e, stranded | FO adapter ST/ST MultiMode simplex | RJ45 connector 10-pack Cat.5e shielded | RJ45 plug transparent | Anti-kink sleeve 10-pack grey
电话:400-900-3095
QQ:800152669

NPORT 5410Family Information

  • Serial device servers for Ethernet
  • NPort servers from Moxa allow connection of devices with a serial interface (RS232/422/485) in TCP/IP networks, for transmission of serial data over a local network or via the Internet with no restriction on the distance. Serial devices such as measuring instruments, barcode readers, label printers, and so on, can thus be centrally controlled and evaluated from any location. Thanks to the various operating modes, NPort servers can be used for virtually all serial applications:
  • Real COM Mode: In order to enable a computer to access the interfaces of the NPort server, virtual COM/TTY ports are created with the aid of driver software under Windows/Linux. In this way the existing applications can be used for serial communications.
  • Pair Connection Mode: With the aid of two Nport servers (5110/DE-211/DE-311), two serial devices can be connected directly to each other via a local Ethernet or via the Internet.
  • Ethernet Modem Mode: With this operating mode, computers with non TCP/IP-capable operating systems (e.g. MS-DOS) are also able to access Nport servers via networks/Internet. To do this, an additional Nport server is connected to the serial interface of the computer, and this is then integrated in the network at the Ethernet port. The serial connection is set up via a modem
  • Socket Modes: TCP Server/Client, UDP Server/Client

NPORT 5410产地与重量

Country of origin Taiwan (TW)
Manufacturer Moxa
Gross weight (incl. package) 720.0 Gram
Dimensions (incl. package) 215 x 150 x 75 MM
Customs number 8517620000
UNSPSC (v5.03) 43172001
