300-76-160,Switched-mode power supply / 20 A, 787-742, Wago
| Output voltage 1, nominal | 24 VDC |
| Output current 1 max. | 20 A |
| Input voltage, nominal | 400 VAC |
| Phases | 3 |
| Outputs | 1 |
| Width | 110 mm |
| Depth | 151 mm |
| Height | 130 mm |
| Output voltage 1 min. | 22 VDC |
| Output voltage 1 max. | 28 VDC |
| Input voltage, AC min. | 325 VAC |
| Input voltage, AC max. | 575 VAC |
| Input voltage, DC min. | 460 VDC |
| Input voltage, DC max. | 800 VDC |
| Operating temperature min. | -25 °C |
| Operating temperature max. | +70 °C |
| Input frequency min. | 47 Hz |
| Input frequency max. | 63 Hz |
| Connection | Terminal |
| Protection rating | IP 20 |
| Weight | 1930 g |
