144-36-724,Cable connector, M12 4-pin, ELWIST 4012 PG7, Belden Hirschmann
Datasheet
| Poles | 4 |
| Gender of contacts | Male |
| Series | M12 Hirschmann |
| Connector Design | angled |
| Protection rating | IP 67 |
| Locking type | Screw locking M12 x 1 |
| Size | M12 |
| Rated current | 4 A |
| Termination type | Screw Terminal |
| Contact material | CuSn+Sn |
| Rated voltage | 250 VAC/DC |
| Housing Material | Polyamide (PA/Nylon) |
| Cable entry max. | 6 mm |
| Connection max. | 0.75 mm2 |
| Max. temperature | +90 °C |
| Cable entry | 4...6 mm |
| Connection | 0.75 mm2 |
| Temperature range | -25...+90 °C |
