110-48-609,Converter FR-E740 0.4 kW, 380...480 VAC 3-phase, FR-E740-016SC-EC, Mitsubishi Electric
Datasheet
| Rated output | 0.4 kW |
| Protection rating | IP 20 |
| Operating voltage | 380...480 VAC |
| Rated current | 1.6 A |
| Output frequency | 0.2...400 Hz |
| Operating temperature | -10...+50 °C |
| Operating voltage type | 3-phase |
| Dimensions W x H x D | 140 x 150 x 120 mm |
| Clock frequency | 0.7...14.5 kHz |
| Input frequency | 50/60 Hz |
| Overload | 200% for 3 sec, 150% for 60 sec |
| Start-up torque | 200% @ 0.5 Hz |
| Analogue input | 1 x 0...(5) 10 VDC or 4...20 mA DC |
| Digital input | 6 |
| Analogue output | 1 x 0...10 V |
| Digital output | 2 |
| Relay output | 1 |
