148-41-514,Female header Screw Connection 10P, BLA 10 SN OR, Weidmüller
Datasheet
| Pitch | 5.08 mm |
| Poles | 10 |
| Gender of contacts | Female |
| Connection direction | straight |
| Termination type | Screw Connection |
| Rated voltage to EN | 250 VAC/DC |
| Rated current to EN | 10 A |
| Cross-section max. | 2.5 mm2 |
| Cross-section min. | 0.2 mm2 |
| Manufacturer Article n° | 1282560000 |
| Rated voltage to UL | 300 VAC/DC |
| Rated current to UL | 10 A |
| Test voltage | 4 kV |
| Temperature range | -20...+120 °C |
| Connection cross-section | 0.2...2.5 mm2 solid 0.2...1.5 mm2 stranded |
| Housing Material | Polybutylene terephthalate (PBT) |
| Combustibility class | UL 94 V-0 |
