PeakTech 4060 MV -

Function generator 1x20 MHz, PeakTech 4060 MV, PeakTech

PeakTech PeakTech 4060 MV
声明：图片仅供参考，请以实物为准！
制造商产品编号：
PeakTech 4060 MV
仓库库存编号：
110-95-153
技术数据表：
View PeakTech 4060 MV Datasheet Datasheet
订购热线： 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大，部分产品信息可能未能及时更新，下单前请与销售人员确认好实时在库数量，谢谢合作！

PeakTech 4060 MV技术参数

Sine max. 20 MHz
Channel analog 1
Waveforms DC
Noise
Ramp
Sine
Square
Triangle

PeakTech 4060 MV产品信息

Sine resolution 0.01 mHz
Interfaces USB
TTL/CMOS
Modulation types AM
FM
FSK
PM
PWM
Amplitude sine max. @ 50 Ohm 10 Vpp
Amplitude sine max. @ idle 20 Vpp
DC offset (peak AC + DC) @ 50 Ohm ±5 V
Instrument functions Burst
Linear Sweep
ARB max. 1 MHz
Amplitude sine resolution @ 50 Ohm 5 mVpp
Amplitude sine resolution @ idle 5 mVpp
DC offset (peak AC + DC) @ idle ±10 V
ARB resolution 0.01 mHz
Vertical resolution ARB 8 Bit
Display 6 digits
Electrical supply 100...240 V @ 50...60 Hz
Dimensions L x W x H 310 x 255 x 100 mm
Weight 2 kg
Delivery with Documentation CD
Output cable
Power cable
Software
USB cable

PeakTech 4060 MV配套产品

电话:400-900-3095
QQ:800152669

PeakTech 4060 MVFamily Information

  • 6-digit LED display for frequency, 4 digits for amplitude
  • RF accuracy: up to a factor 10-5
  • 10 μHz frequency resolution over the entire frequency band
  • Direct, digital setting via keypad or selection by rotary switch
  • Start and end frequency of the sweep can be set arbitrary
  • Frequency or period, virtual amplitude value or peak-to-peak value can be selected
  • USB Device port for control with PC software
  • With built-in 10 W power amplifier from 100 Hz to 10 kHz with 22 Vpp

PeakTech 4060 MV产地与重量

Country of origin China (CN)
Manufacturer PeakTech
Gross weight (incl. package) 15.0 Gram
Dimensions (incl. package) 0 x 0 x 0
Customs number 8543200000
UNSPSC (v5.03) 41113636
EAN 4250569401084
