110-29-587,LCR measuring bridge 200.00 MOhm 10000 mF 75000 H, HIOKI IM 3533, Hioki
Datasheet
| Ohm max. | 200.00 MOhm |
| F max. | 10000 mF |
| H max. | 75000 H |
| Ohm resolution | 10 mOhm |
| Min. Temperature | -10 °C |
| Max. temperature | +99.9 °C |
| Dissipation factor D min. | 0.00001 |
| Dissipation factor D max. | 9.99999 |
| Quality factor Q min. | 0 |
| Quality factor Q max. | 99999.99 |
| Measurement frequency | 200 kHz...1 mHz |
| Measuring function |
|Y|
|Z| θ R ESR DCR X G B C L D Q N M T |
| Interfaces |
Ext I/O
USB USB host (Data Storage To USB Stick) GPIB (Optional) LAN (Optional) RS232 (Optional) |
| Description | LCR measuring bridge |
| Display | 5.7" colour TFT-LCD |
| Weight | 3.1 kg |
| Dimensions L x W x H | 168 x 330 x 119 mm |
| Delivery with |
Swiss power cable is supplied for Swiss Customers
Documentation CD Manual Power cable |
