110-95-100,Multimeter benchtop TRMS AC 1000 VDC 10 ADC, PeakTech 4000, PeakTech
Datasheet
| Type of measurement | TRMS AC |
| Digits | 50000 |
| Bandwidth VAC | 20 kHz |
| Bandwidth AAC | 20 kHz |
| VAC max. | 1000 VAC |
| VAC resolution | 1 μV |
| VDC max. | 1000 VDC |
| VDC resolution | 1 μV |
| ADC max. | 10 ADC |
| ADC resolution | 0.01 μA |
| AAC max. | 10 AAC |
| AAC resolution | 0.01 μA |
| Ohm max. | 50 MOhm |
| Ohm resolution | 0.01 Ohm |
| Safety to EN61010 | CAT II 1000 V |
| Hz max. | 2000 kHz |
| Hz resolution | 0.01 Hz |
| F max. | 5000 μF |
| Measuring function |
Continuity tester
Diode tester Hold Data logger Relative mode Duty cycle Internal memory |
| Instrument functions |
Backlight
Range selection, automatic |
| Interfaces |
RS232
USB |
| Electrical supply | 100...240 V @ 50...60 Hz |
| Guarantee | 3 years |
| Dimensions L x W x H | 320 x 260 x 100 mm |
| Weight | 3.1 kg |
| Design | Bench |
| Delivery with |
Battery
Hard case Test lead Manual Software USB cable Power cable |
