176-09-175,Multimeter digital FLUKE 88-V/A RMS 20000 digits 1000 VAC 1000 VDC 10 ADC, FLUKE 88-V/A, Fluke
Datasheet
| Type of measurement | RMS |
| Display | 20000 digits |
| Bandwidth VAC | 5 kHz |
| Bandwidth AAC | 5 kHz |
| Safety to EN61010 |
CAT III 1000 V
CAT IV 600 V |
| VAC max. | 1000 VAC |
| VAC resolution | 100 μV |
| VDC max. | 1000 VDC |
| VDC resolution | 100 μV |
| ADC max. | 10 ADC |
| ADC resolution | 0.1 μA |
| AAC max. | 10 AAC |
| AAC resolution | 0.1 μA |
| Ohm max. | 50 MOhm |
| Ohm resolution | 0.1 Ohm |
| F max. | 10 mF |
| F resolution | 0.01 nF |
| Hz max. | 200 kHz |
| Hz resolution | 0.01 Hz |
| Sensor type/thermocouples | K |
| °C measurement range | -200...+1090 °C |
| °C resolution | 0.1 °C |
| Measuring function |
Continuity tester
Car measuring function Diode tester Hold Min./max. value RPM measurement |
| Instrument functions |
Analogue bargraph
Backlight Removable holster |
| Electrical supply | 1 x 6LR61/9V |
| Guarantee | Lifetime |
| Dimensions L x W x H | 186 x 86 x 32 mm |
| Weight | 625 g |
| Description | Auto multimeter combo kit |
| Design | Handheld |
| Protection rating | IP 30 |
| Delivery with |
Battery
Holster Magnetic hanging kit Test lead Probes Crocodile clip Temperature probe Rotation sensor Hard case Manual |
