176-09-408,Multimeter digital TRMS AC 50000 digits 1000 VAC 1000 VDC 10 ADC, U1251B, Keysight
Datasheet
| Type of measurement | TRMS AC |
| Display | 50000 digits |
| Bandwidth AAC | 20 kHz |
| Safety to EN61010 |
CAT III 1000 V
CAT IV 600 V |
| VAC max. | 1000 VAC |
| VAC resolution | 1 μV |
| VDC max. | 1000 VDC |
| VDC resolution | 1 μV |
| ADC max. | 10 ADC |
| ADC resolution | 0.01 μA |
| AAC max. | 10 AAC |
| AAC resolution | 0.01 μA |
| Ohm max. | 500 MOhm |
| Ohm resolution | 10 mOhm |
| F max. | 100 mF |
| F resolution | 0.001 nF |
| Hz max. | 20 MHz |
| Hz resolution | 0.001 Hz |
| Sensor type/thermocouples | K |
| °C measurement range | -200...+1372 °C |
| °C resolution | 0.1 °C |
| Measuring function |
Continuity tester
Diode tester Hold Min./max. value Relative mode |
| Instrument functions |
Analogue bargraph
Backlight |
| Interfaces | USB |
| Electrical supply | 1 x 6LR61/9V |
| Guarantee | 3 years |
| Dimensions L x W x H | 203.5 x 94.4 x 59 mm |
| Weight | 504 g |
| Description | Digital multimeter, TRMS |
| Design | Handheld |
| Delivery with |
Battery
Test lead Manual |
