144-03-070,Panel-mount socket 693 series 4-pole Poles 3+PE, 09-4224-00-04, Binder
Datasheet
| Series | 693 |
| Poles | 3+PE |
| Connector Design | Round or elliptical shaped Flange |
| Locking type | Screw locking |
| Mounting | Panel mount |
| Nominal current | 16 A |
| Gender of contacts | Female |
| Description | Panel-mount sockets 693 series |
| Termination type | Screw Connection |
| Connection | 2.5 mm2 |
| Rated voltage | 400 VAC |
| Housing Material | Polybutylene terephthalate (PBT) |
| Protection rating | IP 67 |
| Contact material | CuZn(Sn)+Ag |
| Combustibility class | UL 94 V-0 |
| Temperature range | -40...+100 °C |
