172336-1 -

Pin housing Pitch4.14 mm Poles 1 x 2 Single row / Free hanging/cable mount / straight / accepts male or female contacts MATE-N-LOK Mini Universal, 172336-1, TE Connectivity

TE Connectivity 172336-1
声明：图片仅供参考，请以实物为准！
制造商产品编号：
172336-1
仓库库存编号：
300-11-982
技术数据表：
View 172336-1 Datasheet Datasheet
订购热线： 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大，部分产品信息可能未能及时更新，下单前请与销售人员确认好实时在库数量，谢谢合作！

172336-1技术参数

Pitch 4.14 mm
Poles 1 x 2
Series MATE-N-LOK Mini Universal
Gender of housing Male
Housing Material Polyamide (PA 66)

172336-1产品信息

Connector Design Single row
Free hanging/cable mount
straight
accepts male or female contacts
Connection principle Wire-Wire
Rated current 9.5 A
Rated voltage 600 VAC/DC
Test voltage 1500 V
Insulation resistance 1000 MOhm
Temperature range -55...+105 °C
Combustibility class UL 94 V-0

172336-1您可能还对以下元器件感兴趣

  • 参考图片
  • 制造商 / 说明 / 型号 / 仓库库存编号
  • PDF
  • 操作
电话:400-900-3095
QQ:800152669

172336-1Family Information

Series Description
  • Compact design
  • Protected against polarity reversal, and self-latching
  • Pins and sockets are insulated and safe to touch
  • Socket housing for snap-in assembly (except for 1-pin version) or floating connection
  • Housings can be equipped with pin contacts or socket contacts
  • Nominal current depends on temperature and cross-sectional area of connection

172336-1产地与重量

Country of origin Singapore (SG)
Manufacturer TE Connectivity
Gross weight (incl. package) 1.0 Gram
Dimensions (incl. package) 24 x 15 x 7 MM
Customs number 8538909999
UNSPSC (v5.03) 30211816
