144-19-685,Plug housing Pitch6.35 mm Poles 3 x 3 accepts male or female contacts / Multi row MATE-N-LOK Universal, 1-480706-0, TE Connectivity
Datasheet
| Pitch | 6.35 mm |
| Poles | 3 x 3 |
| Series | MATE-N-LOK Universal |
| Connector Termination | Crimp Termination |
| Gender of housing | Male |
| Housing Material | Polyamide (PA/Nylon) |
| Connector Design |
accepts male or female contacts
Multi row |
| Connection principle |
Wire-Board
Wire-Wire |
| Rated current | 19 A |
| Rated voltage | 600 VAC/DC |
| Test voltage | 5000 V |
| A | 20.3 mm |
| B | 27.4 mm |
| Insulation resistance | 1000 MOhm |
| Temperature range | -55...+85 °C |
| Combustibility class | UL 94 V-2 |
