IT 258 -

Pulse Transformer 2.5 mH 1:1, IT 258, Schaffner

Schaffner IT 258
声明：图片仅供参考，请以实物为准！
制造商产品编号：
IT 258
仓库库存编号：
156-65-363
技术数据表：
View IT 258 Datasheet Datasheet
订购热线： 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大，部分产品信息可能未能及时更新，下单前请与销售人员确认好实时在库数量，谢谢合作！

IT 258技术参数

Rated voltage 750 VAC
Rise time 0.25 μs
Transformation ratio 1:1

IT 258产品信息

Voltage-time area 250 Vμs
Coupling capacitance 80 pF
Primary inductance 2.5 mH
Trigger current 250...1000 mA
Test voltage 3.2 kV
Primary resistance 0.6 Ohm
Secondary resistance 0.7 Ohm
Leakage inductance 3 μH
Housing no. 3
Related Products: SMD transformer 2 mH | SMD transformer 3 x 10 uH | 10/100 Base-T magnetics module 350 uH Ports=1 | LAN transformer SMD | SMD transformer 320 uH
Related Manufacturers: Würth Elektronik | Schurter | EPCOS | Fastron | Maxxtro
Related Categories: Filters | Inductors | PCB Transformers | Power Cords & Electrical Power Cable Assemblies
电话:400-900-3095
QQ:800152669

IT 258Family Information

  • Many different uses
  • Thyristor and triac ignition
  • Actuation of bipolar transistors
  • Triggering of of FET's and MOSFET's for heavy duty switches
  • As coupling transformer for rapid data transmission and galvanic separation in telephone exchanges

IT 258产地与重量

Country of origin Switzerland (CH)
Manufacturer Schaffner
Gross weight (incl. package) 7.0 Gram
Dimensions (incl. package) 17 x 12 x 17 MM
Customs number 8504318090
UNSPSC (v5.03) 30211501
EAN 7612774450009
