137-20-943,Signal relay 24 VDC 2880 Ohm 200 mW SMD, 4-1462037-7, TE Connectivity
Datasheet
| Relay type | Monostable |
| Contacts | 2 change-over (CO) |
| Ucoil | 24 VDC |
| Connection | SMD |
| Manufacturer Article n° | IM07GR |
| Switching current |
2 A @ 30 VDC
0.27 A @ 220 VDC 0.25 A @ 250 VAC |
| Switching power |
60
W
62.5 W |
| Contact material | PdR+Au |
| Rcoil | 2880 Ohm |
| Pcoil | 200 mW |
| Switching voltage |
250
VAC
220 VAC |
| Dimensions L x W x H | 10 x 6 x 5.65 mm |
| Test voltage | 1 kV |
| Pitch |
3.2
mm
2.2 mm |
| Protection rating | IP 67 |
| Temperature range | -40...+85 °C |
| Insertion loss | 0.03 dB@ 100 MHz; 0.33 dB @ 900 MHz |
| Voltage standing wave ratio (V.S.W.R.) | 1.06@ 100 MHz; 1.49 @ 900 MHz |
