175-31-272,SMD LED yellow 2.05...2.65 V SMD, LYCN5M-FAGA-36-1, Osram Semiconductors
Datasheet
| Package | SMD |
| Transmission angle | 60 ° |
| Light colour | yellow |
| Case colour | colourless |
| Housing type | clear |
| Peak wave length | 594 nm |
| Luminous intensity max. | 12 cd |
| Dominant wavelength | 590 nm |
| Forward current | 140 mA |
| Luminous flux max. | 22.4 lm |
| Luminous flux min. | 11.2 lm |
| Operating temperature | -40...+125 °C |
| Conducting-state voltage max. | 2.65 V |
| Conducting-state voltage min. | 2.05 V |
| Technology | Thinfilm |
| Forward voltage | 2.05...2.65 V |
| Dimensions W x D x H | 3 x 2.4 x 3 mm |
| Luminous intensity | 12 cd |
| Luminous flux | 11.2...22.4 lm |
