Switched-mode power supply 130 W 1 output, 13100-092, Pentair Schroff

Pentair Schroff 13100-092
声明：图片仅供参考，请以实物为准！
制造商产品编号：
13100-092
仓库库存编号：
169-94-164
技术数据表：
View 13100-092 Datasheet Datasheet
订购热线： 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大，部分产品信息可能未能及时更新，下单前请与销售人员确认好实时在库数量，谢谢合作！

13100-092技术参数

Power 130 W
Output voltage 1 10.6...15.4 VDC
Output current 1 11 A
AC input voltage 90...254 VAC

13100-092产品信息

Efficiency 80 %
Residual ripple <200 mVss
System deviation, load <100 mV (0 - 100% Iout)
System deviation, supply <100 mV
Operating temperature 0...+70 °C
MTBF >310000 h
Input frequency 50...60 Hz
Mains buffering >10 ms

13100-092替代产品

  • 参考图片
  • 制造商 / 说明 / 型号 / 仓库库存编号
  • PDF
  • 操作
Related Manufacturers: Hammond | Mean Well | Fibox | Traco Power | Bopla
Related Categories: 19" Subracks & Parts | 19'' Enclosures | 19'' Enclosure Accessories | Accessories | Heating, Ventilation & Air Conditioning
Related Products: Power supply 12 VDC/1.5 A | Power supply 5 VDC/1.0 A | Switched-mode power supply | Power supply 24 VDC/0.83 A | Switched-mode power supply / 5 A
电话:400-900-3095
QQ:800152669

13100-092Family Information

  • For 19" mounting
  • Primary switching
  • Single or triple voltage
  • Wide input voltage range
  • Short-circuit proof, over-voltage protected output
  • Fitted with outputs for external voltage sensing
  • Output voltage can be fine-adjusted
  • Parallel connection with current sharing bus (not MAX 312)
  • Power factor correction PFC (not SEK)
  • Connection via 15-pole euro connector of type H DIN41612
  • Anodized front panel as accessory

13100-092产地与重量

Country of origin Germany (DE)
Manufacturer Pentair Schroff
Gross weight (incl. package) 1135.0 Gram
Dimensions (incl. package) 285 x 210 x 115 MM
Customs number 8504408290
UNSPSC (v5.03) 24102001
