169-31-668,Switched-mode power supply, TOP 100-124, Traco Power
Datasheet
| Power | 100 W |
| Output voltage 1, nominal | 24 VDC |
| Output voltage 1 | 24 VDC |
| Output current 1 | 4.2 A |
| Outputs | 1 |
| AC input voltage | 90...264 VAC |
| Efficiency | 91 % |
| Input voltage, nominal | 100...240 VAC |
| Height | 31.8 mm |
| Width | 50.8 mm |
| Length | 101.6 mm |
| Dimensions L x W x H | 101.6 x 50.8 x 31.8 mm |
| System deviation, supply | 1.0% max. |
| System deviation, load | 1.0% max. |
| Residual ripple | <100 mVPP |
| Operating temperature max. | +70 °C |
| Operating temperature min. | -25 °C |
| Operating temperature | -25...+70 °C |
| Output voltage 1 min. | 24 VDC |
| Output voltage 1 max. | 24 VDC |
| MTBF | 1400000h |
| Input frequency | 47...63 Hz |
| Derating | from 50 °C |
