110-51-942,TFT display 6.2" 640 x 240 Pixel, TCG062HVLBC-G20, Kyocera
Datasheet
| Size | 6.2" |
| Resolution | 640 x 240 Pixel |
| Touchscreen | No |
| Viewing angle | Left: 65°, Right: 80°, Top: 80°, Bottom: 80° |
| Backlight type | LED |
| Brightness | 255 cd/m2 |
| Contrast ratio | 500:1 |
| Interface | Digital (TTL/CMOS) |
| No. of colours | 262000 |
| Dimensions module W x H x D | 173 x 70 x 8.9 mm |
| Active area W x H | 147.84 x 55.44 mm |
| Operating temperature | -20...+70 °C |
| Touch panel design | Resistive 4-Wire, Glass on Glass |
| Viewing angle | 6 o'clock |
| Service life, backlight | 40000 h |
