TMT 15124C -

Switching power supply 15 W 1 output, TMT 15124C, Traco Power

Traco Power TMT 15124C
声明:图片仅供参考,请以实物为准!
制造商产品编号:
TMT 15124C
仓库库存编号:
169-30-580
技术数据表:
View TMT 15124C Datasheet Datasheet
订购热线: 400-900-3095  0755-21000796, QQ:800152669, Email:sales@szcwdz.com
由于产品数据库庞大,部分产品信息可能未能及时更新,下单前请与销售人员确认好实时在库数量,谢谢合作!

TMT 15124C技术参数

Output voltage 1 24 VDC
Output current 1 0.625 A
No. of outputs 1 output
AC input voltage 85...264 VAC
Efficiency 83 %typ.

TMT 15124C产品信息

Dimensions L x W x H 77 x 45 x 26.4 mm
System deviation, supply ±0.1% max.
System deviation, load ±1.0% max.
Residual ripple <150 mVpp
Operating temperature -25...+60 °C
Power 15 W
Derating from 50°C
Assembly type Chassis assembly
Input frequency 47...63 Hz
Insulation voltage 4000 VAC@ 1min

TMT 15124C配套产品

  • 参考图片
  • 制造商 / 说明 / 型号 / 仓库库存编号
  • PDF
  • 参考库存数
  • 操作

TMT 15124C您可能还对以下元器件感兴趣

  • 参考图片
  • 制造商 / 说明 / 型号 / 仓库库存编号
  • PDF
  • 参考库存数
  • 操作
Related Products: Power supply 12 VDC/1.5 A | Power supply 5 VDC/1.0 A | Switched-mode power supply | Power supply 24 VDC/0.83 A | Switched-mode power supply / 5 A
Related Categories: DC / DC Converters | AC / DC Converters | Power Supplies | Inductors | Heat Sinks
Related Manufacturers: Mean Well | Würth Elektronik | Fischer Elektronik | Recom | TDK-Lambda

TMT 15124C参考库存及参考价格

16 有货

可于1-2周内送达
搜索
日本5号仓库直销,订单金额100元起订,满300元含运,满500元含税运,有单就有优惠,量大更优惠,支持原厂订货
CNY 905.84
数量 参考价格
1 +  ¥905.84
5 +  ¥860.89
10 +  ¥815.94
电话:400-900-3095
QQ:800152669在线咨询

TMT 15124CFamily Information

Series Description

±1.0% max. (single) / ±5.0% max. (dual)

  • Ultra-compact, sealed plastic case
  • For print assembly with solder pins or for chassis assembly with screw terminals
  • Universal input 85...264 VAC, 50/60 Hz
  • Radio shielding according to EN 55022, class B and EN 60601-1-2
  • Protection class 2, EN 60536
  • Safety approvals for industrial and medicinal applications
  • Short-circuit and overload proof
  • DIN rail assembly with assembly kit, up to 30 W
  • External input fusing 15 W / 30 W 1 A inactive / 2 A inactive (recommended)
  • Immunity from disturbance EN 60601-1-2,EN 61000-6-1
  • Safety licenses according to EN 60950-1, UL 60950-1, IEC 60601-1, UL 60601-1
  • 3 year guarantee

TMT 15124C产地与重量

Country of origin Japan (JP)
Manufacturer Traco Power
Gross weight (incl. package) 98.0 Gram
Dimensions (incl. package) 80 x 45 x 30 MM
Customs number 8504408290
UNSPSC (v5.03) 30211502
